Mediant 1000 Digital
Fast Track Guide 34 Document #: LTRT-63802
7.2 Updating the Auxiliary Files
The auxiliary files are configuration dat files that are loaded to the gateway (in addition to the ini
file) to enable enhanced gateway provisioning. The following common auxiliary files are available:
CAS, Voice Prompts and Call Progress Tones (CPT). For information on additional auxiliary files,
refer to the digital Mediant 1000 User’s Manual. Table 7-1 presents a brief description of the ini
file and of each auxiliary file.
Table 7-1: ini and Auxiliary Files Descriptions
File Type Description
Ini
Load the file to provision the Mediant 1000 parameters. The Embedded Web Server
enables practically full device provisioning but customers may occasionally require
new feature configuration parameters in which case this file is loaded.
Note that loading the
ini file only provisions parameters that are contained in the ini
file. If a parameter is not specified in the
ini file, values associated with that parameter
are reset to a default value. These values may not be the same as the values that
were configured for the VoIP gateway at the time of manufacture.
Note: After the file has completed loading, the VoIP gateway automatically restarts
(software is loaded from the flash).
CAS Up to 8 different CAS files containing specific CAS protocol definitions.
These files are provided by AudioCodes to support various types of CAS signaling.
Voice Prompts The voice announcement file contains a set of Voice Prompts to be played by the
Mediant 1000 during operation on Call Agent request.
Call Progress
Tones
This is a region-specific, telephone exchange-dependent file that contains the Call
Progress Tones levels and frequencies that the VoIP gateway uses. The default CPT
file is: U.S.A.
¾ To load an auxiliary file via the Embedded Web Server, take these 6
steps:
1. Open the ‘Auxiliary Files’ screen (Software Update menu > Load Auxiliary Files); the
‘Auxiliary Files’ screen is displayed (shown in Figure
7-8).
2. Click the Browse button that is in the field for the type of file you want to load.
3. Navigate to the folder that contains the file you want to load.
4. Click the file and click the Open button; the name and path of the file appear in the field next
to the
Browse button.
5. Click the Send File button adjacent to the field that contains the name of the file you want to
load. An asterisk in the screen section indicates that the file’s loading takes effect on-the-fly
(e.g., Voice Prompts file).
6. Repeat steps 2 to 5 for each file you want to load.
