Mediant 1000 Digital
Fast Track Guide 8 Document #: LTRT-63802
2 Installing the Mediant 1000
Caution Electrical Shock
The equipment must only be installed or serviced by qualified service personnel.
¾ To install your Mediant 1000, take these 4 steps:
1. Unpack the Mediant 1000 (refer to Section 2.1 below).
2. Check the package contents (refer to Section 2.2 below).
3. Mount the Mediant 1000 (refer to Section 2.3 on page 9).
4. Cable the Mediant 1000 (refer to Section 2.4 on page 10).
After connecting the Mediant 1000 to the power source, the power LED on the front panel of the
power supply unit is lit green (after a self-testing period of about 2 minutes). Any power supply
malfunction results in the LED switching off (refer to 6.1 on page 28 for details on the Mediant
1000 LEDs).
When you have completed the above relevant sections you are then ready to start configuring the
gateway (Section 3 on page 12).
2.1 Unpacking
¾ To unpack the Mediant 1000, take these 6 steps:
1. Open the carton and remove packing materials.
2. Remove the Mediant 1000 from the carton.
3. Check that there is no equipment damage.
4. Check, retain and process any documents.
5. Notify AudioCodes or your local supplier of any damage or discrepancies.
6. Retain any diskettes or CDs.
2.2 Package Contents
Ensure that in addition to the Mediant 1000, the package contains:
One or two AC power cables.
Four anti-slide bumpers for desktop installation option (supplied in a small plastic bag).
CD (software and documentation).
RS-232 DB9 adapting cable, two meters in length (direct connection to PC).
This Mediant 1000 Digital Fast Track Installation Guide.
