4.6.2.4 Cancelling the Timer ON/OFF function
1) Select
ON
1
,
OFF1
,
ON1
, or
OFF
2
timer setting interface refers to 6.2.1, cancel the
Timer ON/OFF as below:
* Take ON1 for example:
2) To cancel the î ±rst-stage timing switch: cancel both
ON
1
and
OFF1
;
To cancel the second-stage timing switch: cancel both
ON2
and
OFF
2
;
To cancel the two stage timing switch: cancel all
ON
1
,
OFF1
,
ON2
and
OFF
2
.
Note: Under the Timer ON/OFF setting interface, if the timing symbol and
entire time digits î ·ash at the same time, click
4.Use and Operation Instruction
2.1 Key function instruction
4.1.Interface display
Designation
Mute key
Mode key
On-off key
Up key
Down key
Clock key
Under the heating mode or heating mode under the
automatic mode, the mute key operation is effective and
used to enter and exit the mute mode with one click.
4.2.Key and icon function instruction
Key symbols
It is used to switch the unit mode, temperature setting,
and parameter setting.
It is used to carry out startup & shutdown, cancel current
operation,and return to the last level of operation.
It is used to page up, and increase variable value.
It is used to page down, and decrease variable value.
It is used as user clock, and to carry out timing setting.
Function
10
11
2.2.Icon function instruction
4.Use and Operation Instruction
Icon symbol
Designation
Function
Cooling
symbol
Heating
symbol
Automatic
symbol
Defrosting
symbol
Compressor
symbol
Water pump
symbol
Fan symbol
Mute symbol
Timing symbol
Water outlet
symbol
Water inlet
symbol
Locking key
symbol
Fault symbol
Wireless signal
symbol
Degrees Celsius
symbo
l
Degrees Fahrenheit
symbol
Setting symbol
Second symbol
Minute symbol
Hour symbol
Pressure
symbol
Flow symbol
It will display during cooling (there is no limit to startup &
shutdown, and it is optional when the unit is cooling-only
unit or heating-and-cooling unit).
It will display during heating (there is no limit to startup &
shutdown, and it is optional when the unit is heating-only
unit or heating-and-cooling unit).
It will display under the automatic mode (there is no limit to
startup & shutdown, and it is optional when the unit is heating-
and-cooling unit).
It will display in the defrosting process of the unit.
It will display when compressor is started.
It will display when water pump is started.
It will display when fan is started.
When the timing mute function is started, it keeps bright for a
long time. When it is in mute state, it will flash. Or else, it is off.
It will display after the user sets the timing, and multiple timing
intervals can be set .
When the axillary display area displays the water outlet
temperature, the light is on.
When the main display area displays the water inlet temperature,
the light is on.
When the keyboard is locked, it is on.
In case of unit fault, it is on.
When the unit is connected to WIFI module, it will display
according to the strength of WIFI signal.
When main display area or auxiliary display area displays
degrees Celsius, it is on.
When main display area or auxiliary display area displays
degrees Fahrenheit, it is on.
When the parameter is adjustable, it is on
When main display area displays second digit, it is on.
When main display area displays minute digit, it is on.
When main display area displays hour digit, it is on.
When main display area displays pressure, it is on.
When main display area displays flow, it is on.
to return to the main inter-
face;
4.7. Silent setting
4.7.1 One-click silent function
Notes:
1) If one-click silent and timming silent are stared at the same time, short
press
4.Use and Operation Instruction
2.1 Key function instruction
4.1.Interface display
Designation
Mute key
Mode key
On-off key
Up key
Down key
Clock key
Under the heating mode or heating mode under the
automatic mode, the mute key operation is effective and
used to enter and exit the mute mode with one click.
4.2.Key and icon function instruction
Key symbols
It is used to switch the unit mode, temperature setting,
and parameter setting.
It is used to carry out startup & shutdown, cancel current
operation,and return to the last level of operation.
It is used to page up, and increase variable value.
It is used to page down, and decrease variable value.
It is used as user clock, and to carry out timing setting.
Function
10
11
2.2.Icon function instruction
4.Use and Operation Instruction
Icon symbol
Designation
Function
Cooling
symbol
Heating
symbol
Automatic
symbol
Defrosting
symbol
Compressor
symbol
Water pump
symbol
Fan symbol
Mute symbol
Timing symbol
Water outlet
symbol
Water inlet
symbol
Locking key
symbol
Fault symbol
Wireless signal
symbol
Degrees Celsius
symbo
l
Degrees Fahrenheit
symbol
Setting symbol
Second symbol
Minute symbol
Hour symbol
Pressure
symbol
Flow symbol
It will display during cooling (there is no limit to startup &
shutdown, and it is optional when the unit is cooling-only
unit or heating-and-cooling unit).
It will display during heating (there is no limit to startup &
shutdown, and it is optional when the unit is heating-only
unit or heating-and-cooling unit).
It will display under the automatic mode (there is no limit to
startup & shutdown, and it is optional when the unit is heating-
and-cooling unit).
It will display in the defrosting process of the unit.
It will display when compressor is started.
It will display when water pump is started.
It will display when fan is started.
When the timing mute function is started, it keeps bright for a
long time. When it is in mute state, it will flash. Or else, it is off.
It will display after the user sets the timing, and multiple timing
intervals can be set .
When the axillary display area displays the water outlet
temperature, the light is on.
When the main display area displays the water inlet temperature,
the light is on.
When the keyboard is locked, it is on.
In case of unit fault, it is on.
When the unit is connected to WIFI module, it will display
according to the strength of WIFI signal.
When main display area or auxiliary display area displays
degrees Celsius, it is on.
When main display area or auxiliary display area displays
degrees Fahrenheit, it is on.
When the parameter is adjustable, it is on
When main display area displays second digit, it is on.
When main display area displays minute digit, it is on.
When main display area displays hour digit, it is on.
When main display area displays pressure, it is on.
When main display area displays flow, it is on.
for canceling one-click silent and quitting the timing silent for this
time.
2) At night or the rest time, user can start one-click silent or timing silent
function to reduce the noise.
4.USE AND OPERATION INSTRUCTION
22
14
4.Use and Operation Instruction
6.2 Setting and cancelling the Timer ON/OFF function
4.6. Clock setting
6.1 System time setting
Press " " to
save, and return to
the main interface
Hour digit
flashing
System time setting
interface
Notes: Under the clock setting interface, if there is no operation for 20 s, the system will
automatically memorize use s settings, and return to the main interface; if short press " "
during any operating steps, the changes will not be saved and return to the main interface.
Long press " "
for 2 s to enter into
the system times
setting interface
Short press " "
Press " " or " "
to adjust hour digit
Flashing
Stort press " "
to enter into
the timer setting
interface
Short press" " or
" " to circularly
display among
timer ON1, OFF1,
ON2 and OFF2
6.2.2 Select "," ", " " or " " timer setting interface:
"
1 OFF1 OFF
On On2 2
Timer setting interface
Flashing
Press " " to
save the settings
and skip to the
minute digit setting
Minute digit flashing
Flashing Flashing
Press " " or " "
to adjust minute digit
6.2.1 The wire controller can set up a two-stage timing switch: Timer ON1~ OFF1;Timer ON2~OFF2.
15
4.Use and Operation Instruction
6.2.3 Setting the Timer ON/OFF function
Short press " "
to set hour digit
Flashing
Press " "or " "
to adjust hour
digit
Press " " to
save the settings
and skip to the
minute digit setting
Hour digit flashing
Short press " "
or " " to adjustt
minute digit
Minute digit flashing
Short press " "
to save the settings
Flashing
Flashing
Flashing
Short press " " to save
the settings and return to
the main interface
6.2.4 Cancelling the Timer ON/OFF function
Flashing
Short press " "
Flashing
(hour or minute digit)
Short press " "
to cancel the timer
settings
Flashing
Short press " " to save
the change and return to
the main interface
While enter into the "," ", " " or " " timer setting interface, set the Timer ON/OFF as below:
"
1 OFF1 OFF
ON ON2 2
* Take ON1 for example:
1) Select " "," ", " " or " " timer setting interface refers to 6.2.1, cancel the Timer ON/OFF as below:
1 OFF1 OFF
ON ON2 2
* Take ON1 for example:
Note: Under the Timer ON/OFF setting interface, if the timing symbol and entire time digits flash at
the same time, click " " to return to the main interface;
OFF
ON
1
2
Displays the first-stage timing switch on
Displays Timer ON function on
Displays the second-stage timing switch on
Dsiplays Timer OFF function on
2) To cancel the first-stage timing switch: cancel both " " and " ";
To cancel the second-stage timing switch: cancel both
" " and " " ;
To cancel the two stage timing switch: cancel all " "," ", " " and " " .
1 OFF1
ON
OFF
ON2 2
1 OFF1 OFF
ON ON2 2
Bliká
16
4.Use and Operation Instruction
4.7. Silent setting
7.1 One-click silent function
short press " "
Notes:
1). If one-click silent and timming silentaare stared at the same time, short press " " for
canceling one-click silent and quitting the timing silent for this time.
2). At night or the rest time, user can start one-click silent or timing silent function to reduce
the noise.
7.2 Setting and cancelling the silent function
Keep long press
of " " fo r 2 s
Short press" "
or " "
Short press" " for entering
the hour digit setting of
timing-on silent
Short press" "
or " "
Short press" " for confirming
the timing-on silent, and turn to
the setting of timing-off silent
Short press " " for
entering the hour digit
setting of timing-off silent
Short press" "
or " "
Short press" " for confirming
timing-off silent, saving the changes
and returning to the main interface
Short press " " for
cancelling the timing silent
Flashing
Flashing
Flashing
Flashing
Short press" " for
cancelling the timing
silent
Flashing
Flashing
Short press " " to
save the changes and
turn to the main interface
Flashing
17
4.Use and Operation Instruction
4.9.Fault interface
Keep long press
of " " for 5 s
4.8.Keyboard lock
To avoid others' misoperation, please lock the wire controller after completing
the setting.
When the unit fails, the wire controller can display the corresponding code according to the
fault reason. Refer to the fault table for the specific definition of the fault codes.
Notes:
1).Under the locked screen interface, only unlocking operation is available, and the screen
will be lighten after other operations conducted.
2).Under the OFF interface, locking operation is available , and the operation method is the
same as locking screen under the ON interface.
2).Two or more faults:
1).Single fault:
Short press" "
or " "
Fault code
Fault serial number
Quantity of fault
Short press" "
For example:
Notes:
1). When the silent icon" " is lighten:The timing mute has been set, but it's not under silent
status.
2). When the silent icon" " flash:It's under the silent status.
3). When the silent icon" "disappear: The timingsilent is not set.
Remark:
The wire controller can display the temperature unit as " " or " " according to the unit
model you bought.
To Next Page
Loading...
Need help?
General
