Commissioning
EL34xx 137Version: 1.5
EL3453
Name SM2, PDO assignment SM3, PDO assignment
0x1A07 (L1 Advanced)
0x1A24 (Total Status)
EL3483
Name SM2, PDO assignment SM3, PDO assignment
Default - 0x1A00 (L1 Status)
0x1A0A (L2 Status)
0x1A14 (L3 Status)
0x1A1E (Total Total Status)
0x1A20 (Total Total Advanced)
6.4.2 Settings
"Settings" Tab
Fig.150: "Settings" tab
The "Settings" tab provides direct access to the most important configuration objects in the object data
dictionary. It facilitates the terminal configuration.
