Beckhoff EL34 Series User Manual

Commissioning
EL34xx182 Version: 1.5
Index 80n2 PMX User Scale (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
80n2:0 PMX User Scale Ch.1 Max. subindex UINT8 RO 0x15 (21
dec
)
80n2:01 User Calibration En-
able
Set to true to enable user calibration data. BOOLEAN RW 0x00 (0
dec
)
80n2:11 User Calibration Volt-
age Offset
Value in V REAL32 RW 0x00000000 (0
dec
)
80n2:12 User Calibration Volt-
age Gain
Factor (without unit) REAL32 RW 0x3F800000
(1065353216
dec
)
80n2:13 User Calibration Cur-
rent Offset
Value in A REAL32 RW 0x00000000 (0
dec
)
80n2:14 User Calibration Cur-
rent Gain
Factor (without unit) REAL32 RW 0x3F800000
(1065353216
dec
)
80n2:15 User Calibration
Phase Offset
Value in milliseconds REAL32 RW 0x00000000 (0
dec
)
Index F800 PMX Settings
Index (hex) Name Meaning Data type Flags Default
F800:0 PMX Settings Max. subindex UINT8 RO 0x16 (22
dec
)
F800:01 Reset Interval Manual restart of the measurement and statistics in-
terval
BOOLEAN RW 0x00 (0
dec
)
F800:11 Reference Timing reference for the RMS calculation
Set to "Current" if a current is to be measured without
an applied voltage.
permitted values:
UINT32 RW 0x00000000 (0
dec
)
0 Voltage (default)
1 Current
F800:12 Measurement Range Filter setting for determining the fundamental
permitted values:
UINT32 RW 0x00000000 (0
dec
)
0 25..65 Hz (default)
1 25..400 Hz
2 12..45 Hz
F800:13 Frequency Source Source of the system frequency
permitted values:
BIT1 RW 0x00000000 (0
dec
)
0 Channel 1 (default)
1 Channel 2
2 Channel 3
F800:14 Power Calculation
Threshold
Noise reduction:
Here you can enter a minimum limit value in percent
for the power calculation, below which all values are
zeroed.
REAL32 RW 0x3F800000
(1065353216
dec
)
F800:15 Inaccurate Threshold
Voltage
Limit value for the warning bit: Inaccurate Voltage REAL32 RW 0x3FDC28F6
(1071393014
dec
)
F800:16 Inaccurate Threshold
Current
Limit value for the warning bit: Inaccurate Current REAL32 RW 0x3BC49BA6
(1002740646
dec
)
Index F801 PMX Total Settings PQF
Index (hex) Name Meaning Data type Flags Default
F801:0 PMX Total Settings
PQF
Max. subindex UINT8 RO 0x13 (19
dec
)
F801:11 Nominal voltage A nominal voltage value or set value is required to
calculate the power quality factor (for details see ba-
sic function principles).
REAL32 RW 0x43660000
(1130758144
dec
)
F801:12 Nominal Frequency A nominal frequency or set value is required to calcu-
late the power quality factor (for details see basic
function principles).
REAL32 RW 0x42480000
(1112014848
dec
)
F801:13 PQF Dataset permitted values: UINT32 RW 0x00000001 (0
dec
)
0: default
1: default + unbalace
