Parameterization and commissioning

EL673146 Version: 2.8

ADS-WriteControl for local FC310x/EL6731 addressing (port 200)

AdsState DeviceState State of the

FC310x/

EL6731

Description

STOP (6) 0x00 RUN (5) This will stop the FC310x/EL6731, i.e. the process data

connections to all DP slaves (Data_Exchange) are removed (with

SetPrm,Unlock).

RUN (5) 0x00 STOP (6) This will restart the FC310x/EL6731 after a stop, i.e. the process

data connections to all DP slaves (Data_Exchange) are re-

established (normal DP start-up).

ADS-WriteControl for addressing a configured PROFIBUS device (port 0x1000-0x107E)

AdsState DeviceState State of the

FC310x/

EL6731

Description

STOP (6) 0x00 RUN (5) This will stop the slave, i.e. the process data connection to the

relevant DP slave (Data_Exchange) is removed (with

SetPrm,Unlock).

RUN (5) 0x00 STOP (6) This will restart the slave after a stop, i.e. the process data

connection to the relevant DP slave (Data_Exchange) is re-

established (normal DP start-up).

ADS Error Codes

The 32 bit ADS error code always consists of a general ADS error code (Low Word, see ADS

documentation) and a FC310x/EL6731-specific, unique error code (High Word, -> chapter ADS error codes

[}127]). The appropriate text message will also be displayed in the TwinCAT System Manager Logger.

5.1.5.2 PROFIBUS DPV1

On a C1 connection, the master supports the Read and Write services, and on the C2 connection it supports

the Read, Write, Data_Transport, Initiate and Abort services.

C1 Connection (MSAC-C1)

The C1 connection is reserved for the master that cyclically exchanges data with the slave (C1 master). In

order for a slave to be able to use the C1 connection, the slave must support DPV1 (this means that the line

"DPV1_Slave = 1" and the key word "C1_Max_Data_Len" with an appropriate length must be in the GSD

file). If it is also generally necessary to activate the C1 functionality by setting bit 7 in the PrmData byte 0

(see the slave's Profibus [}96] tab) for the corresponding slave (this is done automatically for those

Beckhoff devices that support DPV1).

MSAC-C1-Read is shown in ADS-Read, and MSAC-C1-Write is represented in ADS-Write:

MSAC-C1 Read

ADS-Read parameters Meaning

Net-ID

Net-ID of the master (see the device's ADS [}92] tab)

Port 0x1000 + station address of the slave

IndexGroup Slot number (DPV1 parameter)

IndexOffset Index (DPV1 parameter)

Length Length of the data that is to be read

Data In response: data that has been read
