3 - 3
Instrument and control functions
EN
3
Multifunction Display
DAYTIME MODE (LIGHT)
1. Turning indicator
2. Turning indicator
3. Engine oil pressure warning lamp
4. Water temperature warning lamp
5. High beam indicator lamp
6. Neutral indicator lamp
7. Abs warning lamp
8. Engine control system trouble warning
lamp
9. Fuel level warning lamp
10. Clock
11. Gear indicator lamp
12. Speedometer
13. Trip meter
14. Odometer
15. Warning indicator
16. Tachometer
17. Fuel level indicator
18. Coolant temperature indicator
19. Bluetooth
20. Mobile signal strength
21. Mobile power display
22. Wi icon
23. Missed call notication
Km/h
GEAR
12:00 am
TRIP A:
0.0
Km
TOT:
0
Km
1 23 4 5 6 7 8 9
19
18
17
14
13
12
11
10
16 15
20 21
22 23
