4/201101 29 2 210 822© BMW AG, Munich (Z/Z) 15
9. Installing and connecting the Bluetooth aerial
The adhesive surfaces must be free from oil and
grease. To ensure a permanent bond, ensure you
observe the colour coding of the adhesive strip.
Cut the adhesive strips K into two 40 mm-long pieces.
Remove the brown film from both pieces and stick them
to the metal side of the Bluetooth aerial B.
Remove the white film from both pieces and stick
Bluetooth aerial B onto the back of the glove compart-
ment (1).
Connect branch N1 of the Bluetooth aerial connecting
cable N to Bluetooth aerial B.
To connect branch N2 grasp it through the side
opening on the dashboard.
Push the glove compartment (1) onto the dashboard
frame (2) and connect branch N2 of Bluetooth aerial
connecting cable N to combox D.
Tighten oval-headed screws G.
Install the glove compartment (1) as per ISTA.
