12
E46iCCVM/ST039/3/21/00
Convertible-Top Switch
The convertible-top switch assembly is located in the center console below the IHKA con-
trol panel. There are two push button switches, one for each direction of travel, that pro-
vide a ground input signal to the CVM for top operation.
Two LEDs are positioned in the center of the switch. The top LED will flash whenever the
top is in operation and not locked to the windshield frame or stored completely in the com-
partment. The lower LED will illuminate, if the top switch is pressed and the storage com-
partment floor is in the open position.
OPEN ROOF
CLOSE ROOF
54E46covswitch0100
ART-E46ICCVMTOP
