Turn key 1 in the topcase lock
to position OPEN.
Press lock barrel 1 forward.
Release lever 2 pops up.
Pull release lever all the way
up.
Topcase lid opens.
Close topcase
with Topcase
OA
Pull release lever 1 all the way
up.
Close topcase lid and hold it
down. Ensure that no items
are trapped between cover and
case.
NOTICE
The topcase can also be locked
if the lock is in the LOCK posi-
tion. Under such circumstances,
ensure that the ignition key is not
in the topcase.
Press release lever 1 down un-
til it engages.
Turn key in topcase lock to the
LOCK position and remove.
Removing topcase
with Topcase
OA
9
122
z
Accessories
