Turn adjusting screw 1 clock-
wise to increase distance be-
tween brake lever and handle-
bar grip.
Turn adjusting screw 1 coun-
terclockwise to decrease dis-
tance between brake lever and
handlebar grip.
NOTICE
The adjusting screw can be
turned more easily if you push
the brake lever forward when
doing so.
Mirrors
Adjusting mirrors
Move the mirror to the desired
position by turning the housing
and the mirror arm.
Spring preload
Setting
It is essential to set the spring
preload of the rear suspension to
suit the load carried by the mo-
torcycle. Increase spring preload
when the motorcycle is heavily
loaded and reduce spring preload
accordingly when the motorcycle
is lightly loaded.
Adjusting spring preload
at rear wheel
Remove seat ( 54).
Remove toolkit 1.
4
49
z
Operation
