The figure on the left side 1 in-
dicates the front tire's inflation
pressure, while the figure on the
right 2 shows the inflation pres-
sure in the rear tire. Immediately
after switching on the ignition, "-
- --" is indicated. The transfer
of the inflation pressure values
does not begin until a speed of
19 mph (30 km/h) is exceeded
for the first time.
The displayed tire inflation pres-
sures refer to a tire air tempera-
ture of 68 °F (20 °C).
If the warning triangle 3
is also shown, a warning
display is concerned. The af-
fected inflation pressure flashes.
The universal warning lamp lights
up in yellow when the affected
figure is at the limit of the ap-
proved tolerance range. If the
monitored tire inflation pressure
is outside the specified range the
universal warning lamp will flash
in red.
Further information on
BMW Motorrad RDC can
be found starting from page
( 85).
3
35
z
Displays
