EN
11
OPERATING
Displays and controls
BMW i Wallbox
Functions:
Charging electric or plug-in hybrid vehicles
1 Status LED
2 Charging cable plug holder
3 Charging cable plug
Start the charging cycle
The status LED is permanently lit in blue when the device is not in use. Connect the
vehicle to the Wallbox if it is not already connected.
The status LED will be lit in orange for several seconds whilst the internal self-tests are
being conducted.
The status LED will then light up again in blue to indicate that the vehicle has been
connected successfully. The charging cycle can then be started from the vehicle.
The status LED will flash in blue whilst the charging cycle is active. The charging cycle is
started by the vehicle and the start can also be delayed depending on the setting in the
vehicle.
