BMW K1200 R User Manual

Operation
3
46
To make the loops accessible:
• Remove the seat and turn it
upside down.
• Pull loops 1 out of holders 2.
• Turn the seat back over and
reinstall.
Mirrors
Adjusting mirrors
• Pivot the mirrors to the
correct position.
If the pivot does not allow
sufficient movement, you can
adjust the mirror arm:
• Push protective cap 1 up
over the threaded fastener
on the mirror arm.
• Slacken union nut 2.
• Turn the mirror arm to the
appropriate position.
• Tighten the union nut.
• Pull the protective cap into
position over the threaded
fastener.

BMW K1200 R Specifications

General

Displacement	1157 cc
Transmission	6-speed manual
Frame	Aluminum bridge-type frame
Front Suspension	BMW Motorrad Duolever
Engine Type	Liquid-cooled, 4-stroke, in-line 4-cylinder
Power	163 hp (120 kW) at 10, 250 rpm
Fuel Capacity	19 liters
Seat Height	820 mm
Rear Suspension	BMW Motorrad Paralever
Front Brakes	Dual 320 mm discs, 4-piston calipers
Rear Brakes	Single disc, 265 mm
Dry Weight	211 kg
