Install the front seat
Position the front seat with
mounts 4 in holders 5 on left
and right and lay it down lightly
on the motorcycle.
Applying pressure to the rear
of the seat, push the front seat
slightly forward and then press
the seat firmly down.
The front seat engages with an
audible click.
Install the rear seat ( 63).
Install the rear seat
Install the front seat ( 63).
Engage rear seat 2 in mount 6.
Push down firmly on the rear
seat, applying pressure to the
front of the seat.
The rear seat engages with an
audible click.
Adjusting seat height
Remove the front seat ( 62).
Turn the front seat upside
down.
Remove seat bars 1 and 2
from holders 3.
The front seat can work
loose and wobble if the two
seat rods are not in the same
position.
4
63
z
Operation
