Installing the Rallye
motorcycle seat
Insert the Rallye motorcycle
seat 1 into the fixtures 2 on
the left and right and sub-
sequently press the rear of the
seat forwards and downwards
until the lock audibly engages.
NOTICE
See the rider's manual of the
vehicle for instructions on how
to remove and install the seats
with Comfort package optional
equipment.
Frame guard
Installing the frame guard
Requirement
The frame guard was not in-
stalled upon vehicle handover.
Requirement
The bonding areas must be dry
and free from dust as well as
grease.
Pull off the protective films
from the foam strips 1 on the
inside.
Position the frame guard 2
and press it on at the bond-
ing areas.
Install the rubber bands 1. Po-
sition the sealing area on the
inside of the frame to prevent
the rubber bands from being
opened by coming into contact
with boots.
Install the frame guard on the
opposite side in the same way.
5
21
z
Operation
