Conversion
Removing luggage carrier
NOTICE
Always install the rear footrests
and grab handles for two-up
mode.
Remove screws 1 and luggage
carrier 2.
Installing the luggage
carrier covers
Position the luggage carrier
covers 2.
Install screws 1.
Grab handle bore trim on
rear frame
8 Nm
Removing the rear
footrest brackets
NOTICE
Always install the rear footrests
and grab handles for two-up
mode.
Remove the screws 1 and
remove the left-hand rear
footrest bracket 2.
It is necessary to remove the
rear silencer before removing
the right-hand rear footrest
bracket.
Removing the rear silencer
( 26).
6
24
z
Off-road use
