BMW S 1000R 2015 User Manual

Make sure the ground is level
and firm and place the motor-
cycle on its side stand.
NOTICE
The volume of the tank can be
utilised to the full only when the
motorcycle is propped on its side
stand.
Open the protective cap.
Use the ignition key to unlock
cap 1 of the fuel tank and pop
the cap open.
Refuel with fuel of the grade
stated below; do not fill the
tank past the bottom edge of
the filler neck.
NOTICE
When refuelling after running on
reserve, make sure that you top
up the tank to a level above re-
serve, as otherwise the new level
will not be registered and the fuel
warning light indicating that the
level is down to reserve will not
be switched off.
NOTICE
The "usable fuel capacity" spe-
cified in the technical data is the
quantity that the fuel tank could
hold if it had been run dry and
the engine had cut out due to a
lack of fuel.
Usable fuel capacity
approx. 17.5 l
Fuel reserve
approx. 4 l
Press the fuel tank cap down
firmly to close.
Remove the key and close the
protective cap.
6
104
z Riding
ProCarManuals.com

BMW S 1000R 2015 Specifications

General

Transmission	6-speed
ABS	Standard
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Max Power	160 hp (118 kW) at 11, 000 rpm
Max Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Weight	207 kg (456 lbs) fully fueled
Seat Height	814 mm (32 in)
Fuel Capacity	17.5 liters (4.6 gallons)
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Dual disc brakes, floating brake discs, diameter 320 mm
Rear Brakes	Single disc brake, diameter 220 mm
