BMW S 1000R 2015 User Manual

Multifunction display
1 Speedometer
2 Gear indicator; "N" indic-
ates neutral
3 with heated handlebar
grips
OE
Operating the heated
handlebar grips ( 60)
4 Coolant temperature
5 General information
( 44)
6 Clock ( 44)
7 Fuel level
8 Riding mode ( 54)
NOTICE
See Section 5 for information on
the display modes for the race
track.
3
24
z Status indicators
ProCarManuals.com

BMW S 1000R 2015 Specifications

General

Transmission	6-speed
ABS	Standard
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Max Power	160 hp (118 kW) at 11, 000 rpm
Max Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Weight	207 kg (456 lbs) fully fueled
Seat Height	814 mm (32 in)
Fuel Capacity	17.5 liters (4.6 gallons)
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Dual disc brakes, floating brake discs, diameter 320 mm
Rear Brakes	Single disc brake, diameter 220 mm
