BMW S 1000R 2015 User Manual

Viewing times
To view the time of your
choice, repeatedly press
button 1 until the display
changes.
Starting timing
Press switch 1 to start timing.
NOTICE
The engine has to be running
in order for the headlight-flasher
signal to be detected.
Every time you cross the start/
finish line, press switch 1 again
to start timing for the next lap.
The data of the preceding lap
are written into memory.
Timing continues even if you
exit the display mode. In the
other display modes, however,
timing of another lap can be
started only by an external sig-
nal.
Infrared receiver
with infrared receiver
OA
An infrared signal provides a con-
venient way of operating the lap
timer. The instrument can be op-
erated in this way only when the
infrared receiver available as an
optional accessory is connected
to the IR receiver (on the right
side, behind the side panel). The
RACETRACK SETUP MENU
enables you to choose between
operation with the headlight-
flasher button and the TRIP/INFO
button, or operation by one or
other of these buttons (see the
section on the SETUP MENU).
A lap timeout can be defined to
stop the receiver from registering
completion of a lap prematurely
in response to spurious signals.
5
68
z On the race track
ProCarManuals.com

BMW S 1000R 2015 Specifications

General

Transmission	6-speed
ABS	Standard
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Max Power	160 hp (118 kW) at 11, 000 rpm
Max Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Weight	207 kg (456 lbs) fully fueled
Seat Height	814 mm (32 in)
Fuel Capacity	17.5 liters (4.6 gallons)
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Dual disc brakes, floating brake discs, diameter 320 mm
Rear Brakes	Single disc brake, diameter 220 mm
