Hold the motorcycle upright,

preferably with the assistance

of a second person (do not

prop the motorcycle on the

side stand).

Measure distance D from bot-

tom edge 1 of the number-

plate carrier to screw 2 of the

chain guard.

Apply the rider's weight to the

motorcycle.

With the assistance of a

second person, measure

distance D between points 1

and 2 again and calculate the

difference (negative spring

displacement) between the two

readings.

Load-dependent adjust-

ment of spring preload

Suspension compression at

rear wheel

20...24 mm (With rider 85 kg)

To reduce negative spring dis-

placement (increase spring pre-

load, in other words), use the

tool from the on-board toolkit

to turn adjusting ring 1 in dir-

ection A.

To increase negative spring

displacement (reduce spring

preload, in other words), use

the tool from the on-board

toolkit to turn adjusting ring 1

in direction B.

Adjusting spring preload

for front wheel

with Dynamic Damping Control

(DDC)

Make sure the ground is level

and firm and place the motor-

cycle on its stand.

Start the engine.

NOTICE

Before adjusting spring preload

make sure there is no load on

the motorcycle; remove all items

of luggage, if carried.

Set the damping (DDC) to SOFT

for one-up riding.

On the race track
