BMW S 1000R 2015 User Manual

NOTICE
You cannot start the motorcycle
with the side stand extended and
a gear engaged. The engine will
switch itself off if you start it with
the gearbox in neutral and then
engage a gear before retracting
the side stand.
For a cold engine start and low
temperatures: pull clutch.
Press starter button 1.
NOTICE
The start attempt is automatic-
ally interrupted if battery voltage
is too low. Recharge the battery
before you start the engine, or
use jump leads and a donor bat-
tery to start.
See the subsection on jump
starting in "Maintenance" for
more details.
The engine starts.
Consult the troubleshooting
chart below if the engine re-
fuses to start. ( 168)
Pre-Ride-Check
The instrument panel runs a test
of the warning lights and the re-
volution counter when the igni-
tion is switched on: this is the
Pre-Ride-Check. The test is
aborted if you start the engine
before it completes.
Phase 1
Telltale and warning lights 1
light up, 'General' warning light
2 shows yellow.
Needle 3 of the revolution
counter moves all the way to the
position for maximum engine
revolutions.
All the segments in the display
light up.
Phase 2
The 'General' warning light
changes from yellow to red.
6
95
z Riding
ProCarManuals.com

BMW S 1000R 2015 Specifications

General

Transmission	6-speed
ABS	Standard
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Max Power	160 hp (118 kW) at 11, 000 rpm
Max Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Weight	207 kg (456 lbs) fully fueled
Seat Height	814 mm (32 in)
Fuel Capacity	17.5 liters (4.6 gallons)
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Dual disc brakes, floating brake discs, diameter 320 mm
Rear Brakes	Single disc brake, diameter 220 mm
