English | 35
Bosch Power Tools 1 609 92A 274 | (13.10.16)
Technical Data
Rotational Laser Level GRL 500 H GRL 500 HV
Article number
3 601 K61 A.. 3 601 K61 B..
Working range (radius)
–without laser receiver, approx.
1)
–with laser receiver, approx.
10 m
250 m
10 m
250 m
Levelling Accuracy
2) 3)
–Horizontal
–Vertical
±0.05mm/m
–
±0.05mm/m
±0.1mm/m
Self-levelling range, typically
±8.5 % (±5°) ±8.5 % (±5°)
Levelling duration, typically
15 s 15 s
Rotational speed
600 min
-1
600 min
-1
Single-axis slope operation
(adjustable via keypad and display)
Accuracy
2)
±8.5 %
±0.1 %
±8.5 %
±0.1 %
Theft alarm system
zz
Calibration interval indicator
zz
Operating temperature
–10...+50 °C –10...+50 °C
Storage temperature
–20...+70 °C –20...+70 °C
Relative air humidity, max.
90 % 90 %
Max. altitude
2000m 2000m
Laser class
22
Laser type
635 nm, <1 mW 635 nm, <1 mW
Divergence of laser line
0.4 mrad (full angle) 0.4 mrad (full angle)
Laser beam Ø at the exit opening, approx.
2)
4mm 4mm
Tripod mount
–Vertical
–Horizontal
5/8"
–
5/8"
5/8"
Weight according to EPTA-Procedure 01:2014
2.3 kg 2.3 kg
Dimensions (length x width x height)
234 x 217 x 194 mm 234 x 217 x 194 mm
Degree of protection
IP 56 (protected against dust
and powerful water jets)
IP 56 (protected against dust
and powerful water jets)
Battery Li-Ion Li-Ion
Rated voltage
7.4 V 7.4 V
Capacity
3 Ah 3 Ah
Number of battery cells
44
Operating time, approx.
25 h 25 h
1) The working range (radius) can be reduced due to unfavourable ambient conditions (e.g. direct sunlight).
2) at 20 °C
3) alongside the axes
For clear identification of your rotational laser level, see the serial number 9 on the type plate.
