36 | English
1 609 92A 274 | (13.10.16) Bosch Power Tools
Assembly
Charging the Batteries of the Measuring Tool and
Laser Receiver (see figures A– B)
f Do not use a different battery charger. The battery
charger provided is matched to the lithium-ion battery in-
stalled in your measuring tool.
f Observe the mains voltage! The voltage of the power
source must correspond with the data on the type plate of
the battery charger.
The measuring tool and laser receiv-
er must be charged only in dry in-
door areas. The charging cable is not permitted for charging
outdoors or in moist environments.
Note: The batteries of the measuring tool and laser receiver
are supplied partially charged. To ensure full capacity of the
batteries, completely charge the batteries before the first
use.
The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.
Charge-control Indicator
The measuring tool must be switched on (see “Switching On”,
page 38) to display the battery charge status of the measur-
ing tool and laser receiver.
If the measuring tool is switched off and the laser receiver is in
the charging/storage station 6, the battery charge status can
be displayed as follows:
The display illumination switches off again after 5 s.
Laser Receiver/Remote Control LR50
Article number
3 601 K69 A..
Receivable wavelength
625–645 nm
Working range (radius)
1) 2)
–Laser Receiverwith Rotational Laser
Level
–Remote Control
250 m
150 m
Receiving angle 70° (±35°)
Measuring accuracy
3)
–Setting “fine”
–Setting “medium”
–Setting “coarse ”
±1mm
±2mm
±3mm
±5mm
±7mm
±10mm
Display size
62 x 31 mm
Reception area
100 x 18 mm
Operating temperature
–10 °C ... +50 °C
Storage temperature
–20 °C ... +70 °C
Relative air humidity, max.
90 %
Max. altitude
2000 m
Activation setting for sleep mode
–After 30 mins without button press
–After 30 mins without any laser de-
tection
z
z
Theft alarm system 0–150m
Calibration interval indicator
z
Weight according to EPTA-Procedure
01:2014 0.3 kg
Dimensions (length x width x height)
152 x 77 x 32 mm
Degree of protection
IP 56 (protected
against dust and
powerful water jets)
Battery
Li-Ion
Rated voltage
7.4 V
Capacity
1 Ah
Number of battery cells
2
Operating time, approx.
25 h
4)
1) The working range (radius) can be reduced due to unfavourable
ambient conditions (e.g. direct sunlight).
2) depends on clearance between laser receiver and rotational laser
level
3) at a distance of 30 m
4) with display illumination deactivated
The serial number 27 on the type plate is used to clearly identify your
laser receiver/remote control.
Battery Charger
Article number 2 610 A16 4..
Charging time
approx. 3 h
Output voltage
12 V
Charging current
5A
Protection class
/II
Display
Indications
Meaning Capacity
Remaining
measuring
time, approx.
29
Battery fully
charged.
60–100 % 15–25 h
30
29
Battery partial-
ly charged.
40–60 % 10–15 h
30
29
Battery partial-
ly charged.
20–40 % 5–10 h
30
29
Battery partial-
ly charged.
10–20 % 2,5–5 h
30
29
Battery should
be recharged.
0–10% 0–2,5h
30
–Press the sleep mode button 21 until the audio
signal sounds.
The battery charge-control indicators 29 and 30
are displayed.
