Initial commissioning | ACS 810 | 47 | en
1 689 989 601 2020-12-01| Robert Bosch GmbH
6.5 Switching on the ACS 810
! The ACS 810 is designed for 230 volts, 50 Hz.
Observe the information on the ACS 810 rating
plate.
1. Stand the ACS 810 on a flat, vibration-proof
surface.
2. Actuate the brake to stop the ACS 810 rolling.
3. Connect the power supply cord to the power
supply.
4. Switch on the master switch.
Conducting display test.
" Date and time (start screen) are displayed.
6.6 Required settings
! The following settings must be checked or changed
during initial commissioning.
i All other settings as well as the factory settings can
be found in Section "Settings".
6.6.1 Setting the language
1. Call up start screen.
2. Press <3> and <Flush> simultaneously and release.
The message ENTER CODE 0000 is displayed.
3. Enter code 2222 and confirm with E.
4. Select "LANGUAGE" with o u and confirm with E.
Available languages are displayed.
5. Select language with o u and confirm with E.
" Language is set.
i Return with <Stop>.
6.6.2 Setting the date and time
1. Call up start screen.
2. Press <3> and <Flush> simultaneously and release.
The message ENTER CODE 0000 is displayed.
3. Enter code 2222 and confirm with E.
4. Select "DATE/TIME" with o u and confirm with E.
Date and time are displayed.
i The cursor is automatically placed on the day's
date.
5. Enter date and time using <0 – 9> and confirm
withE.
" Date and time are set.
i Return with <Stop>.
6.6.3 Set workshop data
i The entry is limited to a maximum of 8 lines with
20 characters each.
i Delete the space before the cursor with <MENU>.
1. Call up start screen.
2. Press <3> and <Flush> simultaneously and release.
The message ENTER CODE 0000 is displayed.
3. Enter code 2222 and confirm with E.
4. Select "GARAGE" with o u and confirm with E.
5. Enter workshop data with <A – Z>,<0 – 9> and
confirm with E.
i Use o u to go to another line.
" Workshop data are set.
i Return with <Stop>.
