– RS-232
– Reader interfaces
– four Wiegand interfaces
– 8 relay outputs
– voltage free, power is supplied externally (dry mode)
– powered by internal power supply (wet mode)
– 8 analog inputs with internal power supply
– Battery buffered SRAM and real time clock (RTC)
– Pluggable Compact Flash card
– Liquid Crystal Display
– Transfer rate host interface RS-485: 38,4 kBit/s
– Transfer rate host interface RS-232: 38,4 kBit/s
– Transfer rate host interface Ethernet: 10/100 Mbit/s
– Transfer rate to the extension interface: 9,6 kBit/s
– Self regulating transmit/receive switching
– Supply voltage: 10 V to 30 Vdc,
– Max current load: 5A
– Tamper contact for external covers
Notice!
If an external power supply is used, this should also guarantee
an uninterruptable power supply (UPS). Example: Bosch power
supply APS-PSU-60 (F.01U.282.970).
System Overview
The Access Controller AMC2-4W is connected between the
management host system and different peripheral devices. By
default, a management host system is connected using Ethernet.
A management host connection using RS-485 or RS-232 is also
possible. Corresponding to the available interfaces, one AMC2
can be connected to each COM port using RS-232 mode. In
RS-485 mode, up to eight access controllers can be combined
on one party line.
3.4
Access Modular
Controller
Introduction | en 17
Bosch Sicherheitssysteme 2016-11 | AMC2-4W |
