Bosch Compress 3400iAWS E User Manual

Operation
Compress 3400iAWS E – 6721852787 (2023/01)
18
Table 25 Operation data
Menu: Energy consump.
Table 26 Total energy consumption data
Menu: Energy consump. > Electric auxiliary heater
Table 27 Energy consumption data for electric booster heater
Menu: Energy consump. > Compressor
Table 28 Energy consumption data for heat pump
Menu: Energy supplied
Table 29 Energy output data for heat pump
Menu: Solar
Table 30 Information about the solar system
Menu: Outdoor temp
The currently measured outside temperature is displayed in this menu. In
addition, a diagram of the outside temperature profile for today and
yesterday (from 00:00 to 24:00 in each case) is displayed here.
Menu: Internet
Table 31 Information about the Internet connection
3.5 Faults
If a fault persists:
▶ Confirm the fault by pressing the selector.
▶ Faults that are still active are displayed by pressing the d key.
▶ Call an authorised contractor or customer service and give them the
fault code and sub-code, as well as the ID no. of the user interface.
Table 32 Your contractor must enter the ID no. here.
Faults on additional heat source:
▶ Check the display of the additional heat source for information.
▶ Reset the additional heat source.
▶ If the fault persists; contact your contractor.
3.6 Connect-Key K 30 RF
Connect-Key K 30 RF is a WLAN communication module for controlling
and monitoring your heating system remotely. It is used as an interface
between the heating system and the Internet.
For further information on how to use and install the Connect-Key K 30
RF, please read the installation manual of the accessory.
A WLAN router, internet connection and the Bosch HomeCom Easy app
are required to use this product.
Op. hours for
comp. cool.
Hours run by the compressor in cooling mode since
commissioning or since the last reset.
Op. hours for
comp. DHW
Hours run by the compressor in DHW operation
since commissioning or since the last reset.
Op. hours for
comp. pool
Hours run by the compressor in pool operation since
commissioning or since the last reset.
Number of
heating starts
Number of compressor starts in heating mode since
commissioning or since the last reset.
Number of
cooling starts
Number of compressor starts in cooling mode since
commissioning or since the last reset.
Number of DHW
starts
Number of compressor starts in DHW operation
since commissioning or since the last reset.
Number of pool
starts
Number of compressor starts in pool operation since
commissioning or since the last reset.
Menu item Description
Total Cumulated total energy consumed by the heating
system.
Menu item Description
Total Cumulated total energy consumed by the electric
booster heater.
Heating Cumulated energy consumed by the electric booster
heater in heating mode.
DHW Cumulated energy consumed by the electric booster
heater in DHW mode.
Pool Cumulated energy consumed by the electric booster
heater in pool heating mode.
Menu item Description
Total Cumulated total energy consumed by the heat
pump.
Heating Cumulated energy consumed by the heat pump in
heating mode.
DHW Cumulated energy consumed by the heat pump in
DHW mode.
Cooling Cumulated energy consumed by the heat pump in
cooling mode.
Pool Cumulated energy consumed by the heat pump in
pool heating mode.
Menu item Description
Total energy
suppl.
Cumulated total energy output of the heat pump.
Heating energy
suppl.
Cumulated energy output of the heat pump in
heating mode.
DHW energy
suppl.
Cumulated energy output of the heat pump in DHW
mode.
Emitted cooling
energy
Cumulated energy output of the heat pump in
cooling mode.
Pool energy
suppl.
Cumulated energy output of the heat pump in pool
heating mode.
Menu item Description
Menu item Description
Solar sensor
(graphic)
Current measured temperatures with display of
position of the selected temperature sensor in the
solar system hydraulics (with graphic visualisation
of the current operating conditions of the actuators
in the solar system).
Solar yield Solar yield for last week, solar yield for current week
and total yield of solar system since the solar system
was commissioned.
Menu item Description
IP connection Status of the connection between communication
module and router.
Server
connection
Status of the connection between communication
module and Internet (via the router).
Connected
network
Status of the connection between communication
module and the network and display of WLAN-SSID.
IP address IPV4 address of the communication module.
SW version Software version of the communication module.
Login data Login name and password for the login into the App
to operate the system via a smartphone.
MAC address MAC address of the communication module.
