Installation Guide
9/0
D8128
Page 12 of 1
3.4.5 D8128D OctoPOPIT Switch Settings for D7212B1
ZONEX 1 D8128D Address Switches
Points 9
through 48
1 2 3 4 5
9-16 ON ON ON ON *
17-24 ON ON ON OFF *
25-32 ON ON OFF ON *
33-40 ON ON OFF OFF *
Refer to Table 10 to set the
OctoPOPIT switches for use with the
D7212B1 Control Panel.
* Line Termination Switch (see
Section 3.1.1.2 Line Termination
Switch Settings).
41-48 ON OFF ON ON *
Table 10: OctoPOPIT Settings - D7212B1
