F 002 DG9 918 2017-10-16| Bosch Limited
Technical data | EPS 610 | 31 en
10. Technical data
10.1 EPS 610
Property Unit Value
Overall dimensions
Length mm 1770
Height mm 1720
Width mm 973
Weight kg 850
Drive motor
Voltage V 400 - 415
Frequency Hz 50
Ingress protection IP32 (Overall bench including HMI)
IP43 (Elactrical cabinet)
Power KW 11
Current (at maximum power) A 28
Speed range (adjustable) RPM 50-4000
Efficiency % 89
Accuracy RPM ± 2 - (For speed above 50 RPM)
Torque - Drive
Speed - 0 – 1500 RPM Nm 72
Speed - 1500 – 4000 RPM Nm 72-26
MGT assembly
Size of measuring glass ml 30 and 180 (calibrated at 27
o
C to achieve accuracy)
Quantity of measuring glasses 8 each
Bench
Moment of inertia of graduated flywheel Kgm² 0.75
Shaft height (mounting rail height to axis of drive coupling) mm 125 ± 0.1
Logic board
Stroke counting Stroke 1 - 9999
Delivery pump capacity
Test-oil – low pressure l/min 16.5
Test-oil – high pressure l/min 1.8
Test-oil heater rating KW 2.5
Test-oil cooling: Connection ½” BSP
Cooling water consumption at 17ºC l/min 15
Range of temperature (adjustable) ºC 30 - 60
Pressure gauges
Internal pressure kPa 0 to 1600
High pressure MPa 0 to 6
Inlet pressure kPa 0 to 600
Low inlet pressure kPa -100 to 300
Filling quantities
Test oil tank l 50
Top tray capacity for contaminated oil l 10
HMI
Color LCD display size inches 5.7
