Bosch EPS 610 User Manual

F 002 DG9 918 2017-10-16| Bosch Limited
32 | EPS 610 | Technical dataen
Property Unit Value
Angular rotation of the display unit degrees 45 (on each side)
Noise
Workplace emission sound pressure level L
PA
with drive motor
running at a speed of 4000 min-1 and without injection pump
dB-A 83.18
Auxiliary power supply
Adjustable DC power supply for start / stop magnet V 12 /24
A 7
Permissible ambient temperature ranges
Maximum ambient temperature °C 40
Operating range °C 5 to 40
Storage temperature °C -25 to 60
Miscellaneous
Average time taken to heat test oil from 25 °C to 45 °C minutes approximately 20 minutes
10.2 Bench layout
1490 for grouting
1762
1420
412
For
grouting
‘0’ POSITION
150
150 (min)
‘0’ POSITION
971
1324
618
Fig. 21: Bench layout
(All dimensions in mm)

Bosch EPS 610 Specifications

General

Brand	Bosch
Model	EPS 610
Category	Test Equipment
Language	English
