Service Manual Bosch IDS 2.0 | 25
Bosch Thermotechnology Corp. | 07.2021
Data subject to change
BOVA 60+BVA 60 For Heating
Airfl ow
(CFM)
ID
(°F)
OD
(°F)
86 72 67 62 57 52 47 42 37 32 27 22 17 12 7 2 -4
1160
60
TC 56.7 56.7 56.7 56.6 56.6 56.3 56.1 56.1 55.5 51.9 49.3 45.1 42.3 40.2 40.3 36.3 33.2
kW 2.20 2.58 2.83 3.09 3.36 3.59 3.92 4.34 4.71 4.56 5.30 5.49 5.30 5.11 4.93 4.74 4.60
70
TC 42.7 42.7 42.6 42.6 42.5 42.5 42.4 42.3 42.3 42.1 40.0 37.5 35.0 34.1 33.3 32.6 30.2
kW 1.81 1.95 2.10 2.26 2.44 2.64 2.90 3.17 3.42 3.68 3.79 3.90 3.94 3.87 3.80 3.72 3.68
75
TC 35.4 35.4 35.4 35.3 35.3 35.3 35.2 35.1 35.1 35.1 35.0 34.8 34.8 33.1 31.7 29.9 28.2
kW 1.60 1.66 1.78 1.91 2.07 2.21 2.38 2.57 2.85 3.05 3.33 3.52 3.79 3.79 3.64 3.53 3.45
80
TC 28.4 28.4 28.4 28.4 28.4 28.3 28.3 28.2 28.1 28.1 28.1 28.1 28.1 28.0 27.9 27.9 27.9
kW 1.34 1.42 1.51 1.61 1.72 1.83 1.99 2.12 2.30 2.44 2.64 2.82 3.03 3.24 3.51 3.83 4.16
1320
(Low
Stage)
60
TC 62.2 62.2 62.2 61.8 61.6 61.5 61.4 60.8 56.1 52.5 49.8 45.5 43.2 42.5 39.9 36.7 34.1
kW 2.34 2.93 3.20 3.44 3.74 4.04 4.40 4.80 4.62 4.48 5.58 5.40 5.22 5.05 4.88 4.71 4.56
70
TC 46.8 46.8 46.8 46.8 46.7 46.7 46.6 46.4 46.2 46.2 43.9 41.1 38.4 37.4 36.5 34.2 31.9
kW 1.74 2.16 2.33 2.52 2.74 2.98 3.24 3.54 3.83 4.13 4.57 4.94 5.39 5.47 5.28 5.09 4.94
75
TC 38.8 38.8 38.8 38.8 38.7 38.7 38.6 38.6 38.6 38.6 38.2 38.3 38.3 37.2 35.9 33.6 31.2
kW 1.61 1.84 1.97 2.12 2.28 2.44 2.62 2.92 3.17 3.39 3.66 3.94 4.25 5.47 5.28 5.09 4.94
80
TC 31.2 31.2 31.2 31.2 31.2 31.1 31.2 31.2 31.1 31.1 31.1 31.1 30.8 30.7 30.7 30.7 30.7
kW 1.42 1.55 1.66 1.77 1.90 2.04 2.18 2.34 2.54 2.70 2.94 3.14 3.33 3.60 3.91 4.30 4.65
1520
60
TC 69.0 69.0 68.5 68.5 68.4 68.3 67.4 61.6 56.6 53.0 52.2 52.7 49.1 45.6 42.1 38.7 36.0
kW 2.64 3.45 3.65 3.98 4.30 4.67 4.92 4.73 4.56 4.44 5.30 5.34 5.18 5.02 4.86 4.70 4.57
70
TC 52.0 52.0 52.0 52.0 52.0 51.9 51.5 51.5 51.4 51.4 48.9 45.8 42.7 41.6 40.6 38.0 36.0
kW 1.99 2.50 2.68 2.91 3.16 3.40 3.63 4.03 4.39 4.76 4.90 5.04 5.09 4.99 4.91 4.80 4.76
75
TC 43.2 43.2 43.2 43.1 43.1 43.1 43.0 42.9 42.8 42.6 42.6 42.6 42.6 40.5 38.8 36.7 34.5
kW 1.71 2.12 2.24 2.40 2.58 2.78 3.04 3.32 3.56 3.82 4.19 4.51 4.90 4.90 4.71 4.56 4.46
80
TC 34.8 34.8 34.8 34.8 34.7 34.7 34.7 34.4 34.7 34.7 34.7 34.2 34.2 34.2 34.2 34.2 33.9
kW 1.48 1.78 1.88 2.00 2.16 2.29 2.46 2.64 2.88 3.10 3.36 3.53 3.80 4.10 4.47 4.92 5.36
1750
(High
Stage)
60
TC 76.1 75.6 75.5 75.5 75.5 72.1 68.2 62.4 57.5 53.8 51.1 47.9 44.6 43.6 42.5 39.8 37.1
kW 3.09 3.97 4.22 4.58 4.96 4.95 4.88 4.71 4.56 4.45 2.10 5.12 5.12 4.98 4.90 4.81 4.63
70
TC 57.4 57.3 57.5 57.4 57.2 56.4 56.2 56.1 55.3 53.6 51.0 47.7 44.5 43.4 42.4 39.7 37.0
kW 2.28 2.87 3.08 3.33 3.60 3.82 4.13 4.56 4.77 4.84 4.99 5.13 5.18 5.08 5.00 4.89 4.84
75
TC 47.8 47.8 47.8 47.7 47.6 47.6 47.5 47.1 47.0 47.0 47.0 47.0 44.0 41.8 40.1 37.9 35.7
kW 1.95 2.40 2.55 2.74 2.96 3.20 3.45 3.73 4.04 4.34 4.78 5.17 5.42 5.42 5.20 5.04 4.93
80
TC 38.6 38.6 38.5 38.5 38.4 38.4 38.2 38.2 38.2 38.2 37.9 37.9 37.8 37.9 37.8 37.2 34.5
kW 1.68 2.02 2.13 2.27 2.43 2.58 2.76 3.01 3.29 3.51 3.74 4.01 4.30 4.68 5.09 5.54 5.39
1880
60
TC 81.2 81.0 81.0 81.0 77.1 72.6 68.6 62.6 58.0 54.2 54.4 53.8 50.0 46.5 43.1 40.2 37.4
kW 3.46 4.40 4.66 5.08 5.02 4.90 4.84 4.69 4.56 4.45 5.27 5.33 5.19 5.05 4.91 4.77 4.65
70
TC 61.6 61.6 61.7 61.6 61.0 60.8 60.9 61.0 56.8 54.2 51.5 48.2 45.0 43.9 42.8 40.0 36.8
kW 2.51 3.18 3.39 3.66 3.90 4.20 4.54 5.03 4.97 4.84 4.99 5.13 5.18 5.08 5.00 4.89 4.84
75
TC 51.3 51.3 51.3 51.1 51.1 51.1 51.0 50.5 50.4 50.4 50.4 50.4 44.6 42.4 40.6 38.4 36.1
kW 2.13 2.62 2.79 2.98 3.26 3.50 3.76 4.08 4.43 4.77 5.27 5.70 5.85 5.85 5.62 5.44 5.32
80
TC 41.4 41.4 41.4 41.4 41.3 41.2 41.2 41.2 41.2 40.9 40.7 40.7 40.7 40.7 40.7 37.7 34.9
kW 1.83 2.21 2.32 2.47 2.64 2.80 3.02 3.32 3.59 3.77 4.09 4.39 4.73 5.13 5.65 5.56 5.41
Table 18
TC refer to total capacity S/T: refer to the ratio of sensible heat and total capacity kW: refer to total input power
