Bose FreeSpace IZA 190-HZ User Manual

Page 20 Installation and Operation English
Setup and Operation pro.Bose.com
Introduction
This guide describes the installation and operating procedures for the following:
• FreeSpace
®
IZA 190-HZ integrated zone amplifier
• FreeSpace IZA 250-LZ integrated zone amplifier
• FreeSpace ZA 190-HZ zone amplifier
• FreeSpace ZA 250-LZ zone amplifier
FreeSpace
®
IZA 190-HZ/IZA 250-LZ integrated zone amplifier
Contents
(1) Power cord
(4) Feet with pins
(1) 4-pin Euroblock for PAGE input
(1) 4-pin Euroblock for REMOTE connections
(1) 2-pin Euroblock for MUTE connection
(8) Spade lugs for OUTPUT connections (LZ only)
(1) 3-pin Euroblock for OUTPUT connection (HZ only)
Front-panel
Note: Front-panel controls and indicators are identical on the FreeSpace IZA 190-HZ amplifier.
FreeSpace IZA 250-LZ
AC power cord
2-pin Euroblock
4-pin Euroblocks (2)
3-pin Euroblock (HZ only)
Spade lugs (8) (LZ only)
Feet with pins (4)

Bose FreeSpace IZA 190-HZ Specifications

General

Amplifier class	D
RMS rated power	90 W
Channels quantity	1 channels
Audio output channels	- channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	1 %
XLR in	Yes
Line inputs (RCA)	2
Line outputs (RCA)	1
Speakers connectivity type	RCA
Product color	Silver
Rack capacity	1U
Volume control	Rotary
Connectivity technology	Wired
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power protection features	Overheating, Short circuit
Power consumption (typical)	15 W
Package weight	4100 g

Weight and Dimensions

Depth	310 mm
Width	214 mm
Height	45 mm
Weight	3200 g
