Mounting Options
The T4S/T8S comes with a 1/4″ (6,3 mm) mounting screw insert. This enables it to be mounted onto a number of
available products that include a 1/4″ (6,3 mm) mounting screw, including a camera tripod stand.
Mounting the T4S/T8S on a Camera Tripod Stand
1. Extend the camera tripod legs and secure at desired height.
2. Remove the bracket from the top of the camera tripod stand and secure the bracket to the bottom of the
T4S/T8S with the screw. Make sure the small indentation on the T4S/T8S and the bump on the bracket are
aligned. See Figure 6.
3. Secure the bracket with the T4S/T8S back onto the camera tripod stand. See Figure 8.
Figure 6. Securing bracket to T4S Figure 7. Bracket attached to T4S
