Brinno TLC200 Pro User Manual

36
Specication
CAMERA
Model TLC200 Pro
LCD Screen 1.44" TFT LCD
Lens Rotating Angle 120°
Waterproof
Optional, (In use with TLC200Pro Weather Resistant Housing (ATH120))
CAPTURE MODE
Time Lapse Auto generated Time Lapse videos
Stop Motion Optional, (In use with Shutter Line (ATS100))
Motion Activated
Optional, (In use with Motion Sensor (ATM110))
SENSOR
Type
1/3" HDR sensor (115dB high dynamic range, The
standard CMOS sensor only have 69dB)
Resolution 1.3 Mega pixel
Pixel size 4.2um
Sensitivity 3650mV/lux-sec (Ultra good low light quality)
OPTICS LENS
Type CS Mount
Aperture F2.0
Field of View D: 112°
Focal Length 14 mm ( 35mm equivalent)
Focus Distance 40 cm ( Minimum)
RECORDING
Time Lapse Video Format: AVI Resolution: 1280x 720
Still Image Format: JPEG (only for using Shutter Line)
Resolution: 1280x 720
Memory Storage SD Card ( Supported up to 32 GB)
TIME INTERVAL
Custom From less than 1 second to 24 hours
POWER
Power source Battery: 4 AA Batteries
DC IN: 5V (Micro USB connector)
DIMENSION
Size (DxWxH) 64x 46x 106 mm
Weight 140 g (without batteries)
Color Black

Brinno TLC200 Pro Specifications

General

Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Memory card slot(s)	Yes
Compatible memory cards	SD
Maximum memory card size	32 GB
Battery type	AA
Power source type	Battery, DC
Number of batteries supported	4
Included memory card size	4 GB
Fixed aperture	2 mm
Angle of rotation	120 °
Rotating direction	Vertical
Lens mount interface	CS mount
Closest focusing distance	0.4 m
Field of view (FOV) angle	112 °
Display type	LCD
Product color	Black
Display diagonal	1.44 \
Megapixel	1.3 MP
Sensor type	CMOS
Time interval	ASAP, Custom
White balance	Auto, Cloudy, Daylight, Fluorescent, Shade, Tungsten
Optical sensor size	1/3 \
Image formats supported	JPG
Micro-USB 2.0 ports quantity	1

Weight and Dimensions

Depth	64 mm
Width	52 mm
Height	107 mm
Weight	140 g
