Brother DCP-8065DN Servise Manual

8-2 Confidential
8.2 LIST OF MAINTENANCE-MODE FUNCTIONS
Maintenance-mode Functions
Function
Code
Function
Reference
Section (Page)
01 EEPROM Parameter Initialization 8.4.1 (8-4)
05 Printout of Scanning Compensation Data 8.4.2 (8-5)
06 Placement of CCD Unit Position for Transportation 8.4.3 (8-9)
08 ADF Performance Test 8.4.4 (8-9)
09 Test Pattern 1 8.4.5 (8-10)
10 Firmware Switch Setting 8.4.6.1 (8-11)
11 Printout of Firmware Switch Data 8.4.6.2 (8-13)
12 Operational Check of LCD 8.4.7 (8-14)
13 Operational Check of Control Panel PCB 8.4.8 (8-15)
32 Sensor Operational Check 8.4.9 (8-16)
53 Received Data Transfer Function 8.4.10 (8-18)
54 Fine Adjustment of Scan Start/End Positions 8.4.11 (8-20)
55 Acquisition of White Level Data and CCD Scanner Area
Setting
8.4.12 (8-22)
67 Paper Feeding and Ejecting Test 8.4.13 (8-23)
74 EEPROM Customizing 8.4.14 (8-23)
80 Display of the Equipment's Log Information 8.4.15 (8-24)
82 Machine Error Code Indication 8.4.16 (8-26)
87 Output of Transmission Log to the Telephone Line 8.4.17 (8-26)
88
Counter Reset After Replacing the Fuser Unit, Laser Unit and
Paper Feed Kit
8.4.18 (8-27)
Cancellation of the Memory Security Mode (Not applicable to
DCP-8060/8065DN and the Japanese model.)
8.4.19 (8-27)

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
