The table below shows the printable areas when printing on Landscape for each paper size.
Size A B C D E F G
Letter
279.4 mm
11.0”
(3,300 dots)
215.9 mm
8.5”
(2,550 dots)
269.3 mm
10.6”
(3,180 dots)
215.9 mm
8.5”
(2,550 dots)
5.0 mm
0.2”
(60 dots)
0 mm
4.2 mm
0.16”
(50 dots)
Legal
355.6 mm
14.0”
(4,200 dots)
215.9 mm
8.5”
(2,550 dots)
345.5 mm
13.6”
(4,080 dots)
215.9 mm
8.5”
(2,550 dots)
5.0 mm
0.2”
(60 dots)
0 mm
4.2 mm
0.16”
(50 dots)
Folio
330.2mm
13.0”
(3,900 dots)
215.9 mm
8.5”
(2,550 dots)
320.0 mm
12.6”
(3,780 dots)
215.9 mm
8.5”
(2,550 dots)
5.0 mm
0.2”
(60 dots)
0 mm
4.2 mm
0.16”
(50 dots)
Executive
266.7 mm
10.5”
(3,150 dots)
184.15 mm
7.25”
(2,175 dots)
256.6 mm
10.1”
(3,030 dots)
184.15 mm
7.25”
(2,175 dots)
5.0 mm
0.2”
(60 dots)
0 mm
4.2 mm
0.16”
(50 dots)
A4
297.0 mm
11.69”
(3,507 dots)
210.0 mm
8.27”
(2,480 dots)
287.0 mm
11.2”
(3,389 dots)
210.0 mm
8.27”
(2,480 dots)
4.8 mm
0.19”
(59 dots)
0 mm
4.2 mm
0.16”
(50 dots)
A5
210.0 mm
8.27”
(2,480 dots)
148.5 mm
5.85”
(1,754 dots)
200.0 mm
7.87”
(2,362 dots)
148.5 mm
5.85”
(1,754 dots)
4.8 mm
0.19”
(59 dots)
0 mm
4.2 mm
0.16”
(50 dots)
A6
148.5 mm
5.85”
(1,754 dots)
105.0 mm
4.13”
(1,240 dots)
138.5 mm
5.45”
(1,636 dots)
105.0 mm
4.13”
(1,240 dots)
4.8 mm
0.19”
(59 dots)
0 mm
4.2 mm
0.16”
(50 dots)
B5 (JIS)
257.0 mm
10.11”
(3,033 dots)
182.0 mm
7.1”
(2,130 dots)
247.0 mm
9.72”
(2,916 dots)
182.0 mm
7.1”
(2,130 dots)
4.8 mm
0.19”
(59 dots)
0 mm
4.2 mm
0.16”
(50 dots)
B5 (ISO)
250.0 mm
9.84”
(2,952 dots)
176.0 mm
6.93”
(2,078 dots)
240.0 mm
9.44”
(2,834 dots)
176.0 mm
6.93”
(2,078 dots)
4.8 mm
0.19”
(59 dots)
0 mm
4.2 mm
0.16”
(50 dots)
B6 (ISO)
176.0 mm
6.93”
(2,078 dots)
125.0 mm
4.92”
(1,476 dots)
166.4 mm
6.55”
(1,960 dots)
125.0 mm
4.92”
(1,476 dots)
4.8 mm
0.19”
(59 dots)
0 mm
4.2 mm
0.16”
(50 dots)
COM10
241.3 mm
9.5”
(2,850 dots)
104.78 mm
4.125”
(1,237 dots)
231.1 mm
9.1”
(2,730 dots)
104.78 mm
4.125”
(1,237 dots)
5.0 mm
0.2”
(60 dots)
0 mm
4.2 mm
0.16”
(50 dots)
MONARCH
190.5 mm
7.5”
(2,250 dots)
98.43 mm
3.875”
(1,162 dots)
180.4 mm
7.1”
(2,130 dots)
98.43 mm
3.875”
(1,162 dots)
5.0 mm
0.2”
(60 dots)
0 mm
4.2 mm
0.16”
(50 dots)
C5
229.0 mm
9.01”
(2,704 dots)
162.0 mm
6.38”
(1,913 dots)
219.0 mm
8.62”
(2,586 dots)
162.0 mm
6.38”
(1,913 dots)
4.8 mm
0.19”
(59 dots)
0 mm
4.2 mm
0.16”
(50 dots)
DL
220.0 mm
8.66”
(2,598 dots)
110.0 mm
4.33”
(1,299 dots)
210.0 mm
8.26”
(2,480 dots)
110.0 mm
4.33”
(1,299 dots)
4.8 mm
0.19”
(59 dots)
0 mm
4.2 mm
0.16”
(50 dots)
DLL
110.0 mm
4.33”
(1,299 dots)
220.0 mm
8.66”
(2,598 dots)
97.5 mm
3.84”
(1,151 dots)
220.0 mm
8.66”
(2,598 dots)
6.27 mm
0.25”
(74 dots)
0 mm
6.27 mm
0.25”
(74 dots)
NOTE:
- The paper sizes indicated here should confirm to the nominal dimensions specified by JIS
except B5 (ISO), B6 (ISO).
- The dot size is based on 300 dpi resolution.
2.1.3.2 PCLXL, PS (BR-Script 3)
You can not print within 4.2 mm (50dots in 300 dpi mode) on all four sides of the paper.

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
