APPENDIX D REFERENCE LIST OF MX-2000/4000/5000/7000 SERIES UNIQUE COMMANDS - 5
3. COMMAND REFERENCE LIST
This section describes the specific commands as listed below used to support the functions of the Mailbox unit.
1) PJL output tray & mode setting
2) PJL mailbox protection & bin number setting
3) PJL avoidance of output bin full
4) PCL output tray setting
5) PS output tray & mode setting
6) PS mailbox protection & bin number setting
For the details on each command, refer to the following sections.
3.1. Commands Descriptions
3.1.1. PJL output tray & mode setting
Format
@PJL SET/DEFAULT OUTBIN=TrayName
Parameter
TrayName*
 UPPER:
Select the printer face-down output tray.
 OPTIONALOUTPUTBIN1:
Select the #1 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN2:
Select the #2 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN3:
Select the #3 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN4:
Select the #4 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN5:
Select the #5 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN6:
Select the #6 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN7:
Select the #7 bin of the Mailbox unit.)
 OPTIONALOUTPUTBIN8:
Select the #8 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN9:
Select the #9 bin of the Mailbox unit.
 OPTIONALOUTPUTBIN10:
Select the #10 bin of the Mailbox unit.
 ALLSTACKER:
Select the stacker function. **
 ALLSORTER:
Select the sorter function. **
* = The tray names are compatible with the HP tray naming.
** = These are unique tray names (parameters).
Default = ALLSTACKER
Explanation
 This command selects the specified output tray and output mode, trays defined as Mailboxes are numbered
from the bottom of the unit upwards
 This command is ignored when there is no specified tray.
 The ALLSTACKER and ALLSORTER parameters are executed for all output trays other than the ones which
are defined and protected as mailboxes. (Refer to Section 3.1.2 'PJL mailbox protection & tray number
setting'.)
 The difference between the SET and DEFAULT selection and the effective period of this setting follow the
PJL specifications.
