Brother PE-DESIGN LITE User Manual

27
Arranging Embroidery Designs
Importing embroidery
design files
Embroidery designs from embroidery cards (.pec),
and files created in the Tajima (.dst), Melco (.exp),
Pfaff (.pcs), Husqvarna/Viking (.hus, .vip, .shv),
Janome (.jef, .sew), Singer (.csd, .xxx) and
embroidery sewing machine (.phc) formats can be
imported and added to the current Design Page.
With this function, you can also add .pes files to the
Design Page, allowing you to combine several files
created with this application.
Toolbar button:
1. Click or File, then Import from File.
→ An Import from File dialog box similar to
the one shown below appears.
2. Select the drive and the folder.
3. To view the contents of the files in the
currently selected folder, click Browse.
→ A Browse dialog box similar to the one
shown below appears.
a Note:
Be sure to select the correct file name
extension from the Files of type box.
b Memo:
• If the Preview check box is selected, the
contents of the selected file will appear in
the Preview box.
• To quit the operation and close the dialog
box, click Cancel.
b Memo:
• This dialog box can be resized so that the
folder contents can be viewed better. The
size of the dialog box is retained until it is
changed again.
• To return to the Import from File dialog
box, click Cancel.
• To see a more detailed design, select a
file, and then click Preview. A Preview
dialog box similar to the one shown below
appears.
• To import the displayed file, click
Import .
• To return to the
Browse dialog box,
click Cancel .
