2.3. Radiation Profile – CTX
Testing
conditions
Testing c
onditions for the CTX were the same as for the S1 TITAN as described in
Rad
iation
Profil
e – S1 TITAN starting on page 21.
Differenc
es
between
in
struments
The CTX uses
the same mix of tubes and detectors used in The S1 TITAN
and
t
he open b
eam
profile is
the same. The angle of the X-ray beam is still 45 degrees, but is pointed toward the back
of the CTX, at the lid when open.
Due to additional shielding, the CTX is heavier than handheld models. When the CTX is used
properly, this shielding reduces measurable radiation outside the enclosure to background level.
Readin
gs
The instru
ment stray radiation profile was collected
–
 Using a
RadEye B20-ER meter.
 At 50keV and 39uA.
 Operating without a filter and with the 5mm spot size.
 Without a sample covering the opening at sample position.
Backgroun
d
radiation
Measured background radiation was 10 to 16

Rem/h
r when the CTX was off. A distance of 10cm
is shown in the following figure, but its background is any space outside the enclosure.
10cm
10cm
10cm
10cm
bkg
bkg
bkg
bkg
bkg
bkg
bkg
bkg
bkg
bkg
bkg
bkg
bkg
bkg
bkg
bkg bkg
bkg
bkg
