VERTEX 70v User Manual 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I
NSTALLATION
3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL INFORMATION
Unpacking and initial installation of VERTEX 70v is done by Bruker service engineers.
The operating company has to provide an installation site that meets the site require-
ments described in this chapter. (See also the technical document Installation Require-
ments for VERTEX 70v provided by Bruker Optik GmbH in advance.)
This chapter contains a list of the standard as well as the optional spectrometer compo-
nents and describes the procedures for connecting the spectrometer:
• to the power supply,
• to a PC,
• to the vacuum pump and
• to the purge gas supply line, if necessary.
For detailed information about how to install the computer, refer to the PC manual.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DELIVERY SCOPE
The basic instrument of VERTEX 70v allows upgrading with additional components and/
or accessories. The delivery scope depends on the spectrometer configuration you
have ordered.
Standard Components
The basic instrument includes the following items:
• VERTEX 70v spectrometer (including the user manual)
• Power cord
• PC compatible data system (if desired, the PC can also be provided by the
customer)
• Data cable (Cat5, crossover cable for 10Base-T Ethernet standard)
• Purge gas hose (OD: 6mm, length: approx. 5m)
• Tool kit (slot-head screw driver, cross-head screwdriver and hex keys of several
sizes, sample preparation tools, 3x spare fuses, IR sensor card, metallic cap
shown in fig. 28)
• Software package OPUS/IR (including the OPUS Reference Manual)
