REAR OF THE 218
21| 46
218 POWER AMPLIFIER
4. Input, right channel
5. BurLink connection
6. Power switch
7. Device fuses (behind cover)
8. Remote IN jack
9. Remote OUT jack
10. Input, left channel
11. Output, right channel, positive
12. Output, right channel, negative
13. Power jack
14. Output, left channel, negative
15. Output, left channel, positive
12
13
14
11
4 5 6 7
8
9 10
15
