Transport | 3
Instruction Manual R5 RA 0063 F5K_EN_en 7 | 32
3 Transport
WARNING
Suspended load.
Risk of severe injury!
● Do not walk, stand or work under suspended loads.
WARNING
Lifting the machine using the motor eye bolt.
Risk of severe injury!
● Do not lift the machine using the eye bolt fitted to the motor. Only lift the machine as shown.
NOTICE
In case the machine is already filled with oil.
Tilting a machine that is already filled with oil can cause large quantities of oil to ingress into
the cylinder. Starting the machine with excessive quantities of oil in the cylinder will immedi-
ately break the vanes and ruin the machine!
● Drain the oil prior to every transport or always horizontally transport the machine.
● To find out the weight of the machine, refer to the chapter Technical Data [➔28] or the name-
plate (NP).
● Make sure that the eye bolt(s) (EB) is/are in faultless condition, fully screwed in and tightened by
hand.
