Canon LV-WX320 User Manual

76
Control Commands
You can control this projector by sending commands via CONTROL port or LAN port.
System Requirement
CONTROL port
LAN port
Control Command
Connection Cable 9-pin RS-232-C Cable (Crossover)
Communication Mode RS-232-C asynchronous, half-duplex communication
Baud Rate 19200 bps
Character Length 8 bit
Parity Check None
Stop Bits 2 bit
Flow Control None
Connection System TCP/IP Connection
Port 33336
Function
Read/
Write
Operation Command (ASCII) Note
Power
W Power On POWER=ON<CR>
Enable during
“Standby” state.
W Power Off POWER=OFF<CR>
R Power Status GET=POWER<CR>
Enable during any
power state.
[Warming up]
g:POWER=OFF2ON
[Cooling down]
g:POWER=ON2OFF
Source
Selection
W Computer1 INPUT=DSUB1<CR>
W Computer2 INPUT=DSUB2<CR>
W HDMI INPUT=HDMI<CR>
W Video INPUT=VIDEO<CR>
W S-Video INPUT=S-VIDEO<CR>
R Current source GET=INPUT<CR>
Audio
Control
W Mute On MUTE=ON<CR>
W Mute Off MUTE=OFF<CR>
R Mute Status GET=MUTE<CR>
W Volume + RC=VOL_P<CR>
W Volume - RC=VOL_M<CR>
R Volume Status GET=AVOL<CR>
