Canon MVX450 User Manual

23
Preparation
E
Step 7: Adjusting the LCD Screen
Rotating the LCD Panel
Open the LCD panel 90 degrees.
• You can rotate the panel downward by 90 degrees.
• You can rotate the panel by 180 degrees toward the lens (allowing the subject to
monitor the LCD screen while you use the viewfinder).
• When the LCD screen is facing the subject, the LCD image will be reversed right-left
and the subject will see a mirror image. In the LCD mirror mode, only the tape and card
operation and the self-timer displays will appear on the LCD screen. All displays will
appear normally on the viewfinder screen.
Rotating the panel by 180 degrees is also useful if you wish to include yourself
when recording with the self-timer ( 51).
LCD Backlight
You can switch the brightness of the LCD screen between normal and bright by pressing
the LCD BACKLIGHT button. This is useful for outdoor recordings.
Press the LCD BACKLIGHT button.
The brightness changes with each press of the button.
 This setting does not affect the brightness of the recording or the viewfinder
screen.
 When using a battery pack, the camcorder retains the setting even if you
change the position of the switch.
 The battery usage time shortens when the LCD screen is set brighter.
Subject can monitor the LCD screen
LCD BACKLIGHT button
Downloaded From VideoCamera-Manual.com Manuals

Canon MVX450 Specifications

General

Filter size	27 mm
Digital zoom	800 x
Optical zoom	20 x
Focal length range	43.7 - 878 mm
Sensor type	CCD
Total megapixels	1.33 MP
Optical sensor size	1/5 \
Effective megapixels (movie)	750000 MP
Display diagonal	2.7 \
Display resolution	123000 pixels
I/O ports	AV
Resolution	640 x 480 pixels
Camera shutter speed	1/2000 ~ 1/6 s
Battery type	BP-208DG
Minimum illumination	2 lx
PictBridge	Yes
USB 2.0 ports quantity	1
Camcorder tape type	Mini-DV
Compatible memory cards	MMC, SD
Viewfinder resolution	113000 pixels
Product color	Silver

Weight and Dimensions

Depth	109 mm
Width	57 mm
Height	77 mm
Weight	430 g
