Carel pCO1 series User Manual

pCO Sistema
Code: +030220336 - rel. 1.5 - 22/12/10
70
10.14 Serial printer protocol
The Serial printer protocol is used to connect the pCO to any printer fitted with an RS232 interface; this allows paper copies to be generated of particularly important
information, for example the trend in the temperature in a cold room over time. The information to be printed can be completely configured in the application.
Instead of the printer, other devices with RS232 serial interface can be connected, for example a terminal emulator or a PC with a program that saves the data received
via the serial link to the hard disk.
Available on the following serial ports
pCO model
pCO modelpCO model
pCO model
Serial port
Serial portSerial port
Serial port
How to select the protocol
How to select the protocolHow to select the protocol
How to select the protocol
pCO
2
1
–
BMS
SERIAL1_PROTOCOL = 14
pCO
1
1
–
BMS
SERIAL1_PROTOCOL = 1
4
2
–
FieldBus
SERIAL2_PROTOCOL = 14
pCO
XS
1
–
BMS
SERIAL1_PROTOCOL = 14
pCO
C
1
–
BMS
SERIAL1_PROTOCOL = 14
pCO
3
1
–
BMS
SERIAL1_PROTOCOL = 14
2
–
FieldBus
SERIAL2_PROTOCOL = 14
Note for pCO
Note for pCONote for pCO
Note for pCO
1
11
1
and pCO
and pCOand pCO
and pCO
3
33
3
:
::
: the protocol cannot be activated on more than one serial port at the same time.
Connectable devices: one serial printer or any other device fitted with RS232 interface.
Specifications
Baud rate: 1200 bps
Communication mode: 8 data bits, no parity, 1 stop bit, no flow control
Connectable devices: 1
Type of cable / max. distance: RS232 cable / max 5m
