Carel pCO3 User Manual

21
+050003290 - 1.4 - 29.09.2006
• use the ↓↑ buttons to select the desired value, and confi rm by pressing the ↵ button. If the value selected is different than the value
saved previously, the screen shown below will be displayed, and the new value will be saved to permanent memory.
Display address
changed
If the fi eld nn is set to the value 0, the terminal will communicate with the pCO
3
controller using the “point-to-point” protocol (not
pLAN) and the “I/O Board address: xx” fi eld will not be displayed, as it no longer has meaning.
pCO
3
: assigning the list of private and shared terminals
At this stage, to modify the list of terminals associated with each individual pCO
3
board, proceed as follows:
• enter confi guration mode by pressing the ↓↑↵ buttons, as described in the previous paragraph;
• press the ↵ button until the cursor reaches the fi eld xx (I/O board address) ;
• use the ↓↑ buttons to select the desired address of the pCO
3
board. The values that can be selected refer to the pCO
3
boards that
are effectively on line. If the pLAN network is not operating correctly, or alternatively no pCO
3
board is connected, the fi eld will not
be able to be modifi ed and will only show “—”;
• pressing the ↵ button again displays the following screens in sequence:
Terminal Config
Press ENTER
to continue
P12:Adr Priv/Shared
Trm1 02 Sh
Trm2 03 Pr
Trm3 None --OK?NO
• here too the ↵ button moves the cursor from one fi eld to another, and the ↓↑ buttons change the value of the current fi eld.
The fi eld P:xx shows the address of the board selected; in the example shown in fi gure, the address 12 has been selected;
• to exit the confi guration procedure and save the data, select the fi eld “OK ?” and set to Yes, then confi rm by pressing the ↵ button.
The fi elds in the “Adr” column represent the addresses of the terminals associated with the pCO3 board address 12, while the Priv/
Shared column indicates the type of terminal.
Important: the pGD terminals cannot be confi gured as “Sp” (shared printer), as they do not have the printer output.
If the terminal remains inactive (no button pressed) for more than 30 seconds, the confi guration procedure is automatically ended
without saving any changes.
NOTES ON USING WINLOAD, BOOT AND BIOS
The most recent version of WinLoad should always be used. Management of the pCO
3
is supported by WinLoad version 3.35, available
at http://ksa.carel.com.
From version 3.36, the download speed for the Bios and the application to the pCO
3
has been increased to 115200 bit/s from the
standard speed of 28800 bit/s, however this change does not require any new settings by the user.
The pCO
3
BIOS and the BOOT are specifi c fi les, and different from the pCO
1
and pCO
2
BIOS and BOOT fi les. Consequently, these
cannot be loaded onto the pCO
3
, and, obviously, the pCO
1
and pCO
2
BOOT and BIOS cannot be loaded onto the pCO
3
.
IMPORTANT WARNINGS
The CAREL product is a state-of-the-art product, whose operation is specifi ed in the technical documentation supplied with the product or
can be downloaded, even prior to purchase, from the website www.carel.com.
The client (builder, developer or installer of the fi nal equipment) assumes every responsibility and risk relating to the phase of confi guration
the product in order to reach the expected results in relation to the specifi c fi nal installation and/or equipment. The lack of such phase
of study, which is requested/indicated in the user manual, can cause the fi nal product to malfunction of which CAREL can not be held
responsible.
The fi nal client must use the product only in the manner described in the documentation related to the product itself.
The liability of CAREL in relation to its own product is regulated by CAREL’s general contract conditions edited on the website www.carel.
com and/or by specifi c agreements with clients.
english
