9. TECHNICAL SPECIFICATIONS
models PJ32S PJ32X PJ32Y PJ32C
POWER SUPPLY
very low voltage
12Vac 10%, 50/60Hz / 12Vdc (11 to 16Vdc)    
230Vac/Vdc, +10/-15%, 50/60Hz
   
low voltage
115Vac/Vdc, +10/-15%, 50/60Hz
   
rated power (VA)
3
accuracy (with reference to the type of probes)
CAREL NTC (C) 1
PTC (C) 3
type of control probe
CAREL NTC (10 K at 25C)    
PTC (985  at 25ºC) 
type of defrost probe
CAREL NTC (10 K at 25C)  
PTC (985  at 25 ºC)
control range:-50 to 90 °C (-50 to 127 °F)
   
operating conditions: -10 to 50 °C, <80% RH
   
storage conditions:-20 to 70 °C, <80% RH
   
USER INTERFACE
2 and ½ digit LED display
   
buzzer signal to indicate:

compressor ON (*)
Top/Eco Top/Eco Top/Eco Top/Eco
defrost ON
Top Top Top Top
continuous cycle ON
Top/Eco Top/Eco Top/Eco Top/Eco
alarm event
Top Top Top Top
special functions
duty setting
   
continuous cycle
   
Multifunction input
 
Multifunction output for alarm relay
  
serial connection
Top Top Top Top
keypad protection
   
programming
   
MECHANICAL SPECIFICATIONS
dimensions (mm): 36x81x65
   
clip-on fastening using bracket
   
fastening from front panel using screws
Top Top Top Top
type of environmental pollution: normal
   
ELECTRICAL SPECIFICATIONS
relay outputs: action type 1C
   
index of protection IP54 for panel mounting
   
connections: screw terminals for cables with min 0.5 mm
2
and max 1.5 mm
2
cross-section, and up to 2.5 mm
2
for crimping terminals
Top Top Top Top
UL approval classification: 250Vac 12/8/5A res. 5/2/1FLA 30/12/6LRA
EN60730-1 classification: 12(2)/6(2)/5(1) AT 250Vac
QUALITY AND ACCURACY
watch dog (self-checking of internal functions)
   
Tab. 9.1
(*): only the Top versions feature the LED signals behind the buttons, the other (Eco) versions feature only the compressor ON
signal using the decimal point of the right-most digit.
