Carel plug-in PJ32C User Manual

plug-in
Cod. +030221881 rel. 1.5 - 26/10/10
49
9.1 Table summarising the characteristics of the relays used
ELECTRICAL SPECIFICATIONS OF THE
RELAYS PRESENT ON THE VARIOUS
MODELS
max current
16A resistive
max current
8A resistive
max current
5A resistive
max current
16 A resistive
2 HP
maximum peak current
30A 12A 6A 72A
maximum commutable resistive current
12A 8A 5A 16A
maximum commutable power (250Vac)
3000VA 2000VA 1250VA 4000VA
maximum inductive load at 250Vac
4 A (cos =0.7) 2A (cos =0.8)
2A
12A (cos =0,7)
maximum commutable voltage
250Vac 250Vac 250Vac 250Vac
VDE0435 classification
16(2) AT 250Vac 8(2) AT 250Vac 5(2) AT 250Vac 16A 250Vac
VDE0461 classification
12(2) AT 250Vac 6(4) AT 250Vac 12(12)A 250Vac
UL classification (*)
(UL approval of the instrument)
250Vac 12A res.
5FLA 30LRA
250Vac 8A res.
2FLA 12LRA
250Vac 5A res.
1FLA 6LRA
250Vac 12A res.
12 FLA 72LRA
instrument classification as per EN60730-1
12(2) AT 250Vac
or 10 (4)A only NO
6(2) AT 250Vac
or 8 (3)A only NO
5(1) AT 250Vac 10(10)A 250Vac
Tab. 9.1.1
(*) Minimum T OFF between two following motor load starting is 60 seconds or more.
9.2 Temperature/resistance values for the NTC thermistors
The temperature probes with NTC thermistors, normally used on the PJ32 controls, feature electrical resistance which changes
according to changes in temperature. Below are the resistance values corresponding to various temperatures.
Table 9.2.2 lists 3 resistance values for each temperature:
 R
std
is the typical resistance value at the indicated temperature;
 R
min
is the minimum value;
 R
MAX
is the maximum value.
In order to be able to check probe operation, the table shows values corresponding to a number of temperatures.
Table of temperature/resistance values for the CAREL NTC temperature probe. Nominal value: 10 k at 25°C.
temperature (ºC)
R
min
(k) R
std
(k) R
MAX
(k)
-40 181.10 188.40 195.90
0 26.74 27.28 27.83
20 11.95 12.09 12.23
50 4.08 4.16 4.24
Tab. 9.2.2
For the PJ32 controllers featuring PTC probe input, refer to the table of temperature/resistance values for the CAREL PTC
temperature probe.
NOMINAL VALUE: 990 at 25 ºC
temperature (ºC)
R
min
() R
std
() R
max
()
-40 545 562 578
0 792 807 820
20 944 952 962
50 1178 1196 1213
Tab. 9.2.3
