ELECTRICAL DATA
Table 8 —24AHA4/124ANS Electrical Data
Unit Size --
voltage series
V/PH
OPER VOLTS* COMP FAN
MCA
MAX FUSE**
or CKT BRK
AMPS
MAX MIN LRA RLA FLA
18--30
208/230/1 253 197
56.3 9.0 0.50 11.8 20
24--30 62.9 10.9 0.50 14.1 25
30--30 73.0 14.1 0.70 18.3 30
36--30 77.0 14.1 1.20 18.8 30
36--50 208/230/3 253 197 71.0 9.0 1.20 12.5 20
36--60 460/3 506 414 38.0 5.6 0.60 7.6 15
Table 9—25HHA4/224ANS Electrical Data
Unit Size
Voltage Series
V/PH
OPER VOLTS COMP FAN
MCA
MAX FUSE**
or CKT BRK
AMPS
MAX MIN LRA RLA FLA
24--30
208/230/1 253 197
58.3 12.8 0.50 16.5 25
30--30 64.0 12.8 1.20 17.2 30
36--30 77.0 14.2 1.20 19.0 30
36--50 208/230/3 253 197 71.0 9.3 1.20 12.8 20
36--60 460/3 506 414 38.0 5.6 0.60 7.6 15
Table 10—40MKCB**C Electrical Data
Indoor Unit Size
BTU/Hr
V--Ph--Hz
Voltage Range Fan Power
Min (V) Max (V) FLA (A) MinCktAmp(A)
Max Fuse CB Amp
(A)
18K 208–230 -- 1 -- 60 187 253 0.332 1 15
24K – 34K 208–230 -- 1 -- 60 187 253 0.8 1 15
Table 11—40MKQB**C Electrical Data
Indoor Unit Size
BTU/Hr
V--Ph--Hz
Voltage Range Fan Power
Min (V) Max (V) FLA (A) Min Ckt Amp (A)
Max Fuse CB Amp
(A)
24K – 34K 208–230 -- 1 -- 60 187 253 0.8 1 15
LEGEND
FLA --- F u l l L o a d A m p s
H A C R --- Heating, Air Conditioning, Refrigeration
L R A --- Locked Rotor Amps
N E C --- National Electrical Code
RLA---RatedLoadAmps(compressor)
*Permissible limits of the voltage range at which the unit will operate satisfactorily
**T i m e --- D e l a y f u s e .
Complies with 2007 requirements of ASHRAE Standards 90.1
