PHYSICAL DATA
Outdoor Unit 38MVC 009 012 012 018 24
System Voltage 115 V 115 V 208/230 208/230 208/230
Nominal Capacity (Btuh) 9000 12000 12000 18000 24000
Operating Weight lb(kg) 70.4(32) 79.2(36) 79.2(36) 116.6(53) 149.6(68)
Refrigerant Type R---410A
Metering Device Capillary Tube at Outdoor
Charge lb (kg) 2.3 (1.0) 2.9 (1.3) 3.0 (1.4) 4.4 ( 2.0) 5.3 (2.4)
Compressor
Type Rotary
Model EA82X1C---1FZDU1 EA108X1C---1FZDU1 PA108X1C---3FZDU PA150X2CS ---3KUU PA200X2CS---3MUU
O i l C h a r g e ( P OE --- o z ) 11.8 11.8 11.8 25.4 25.4
Outdoor Fan
Rpm 900 900 900 840 740
Diameter (in) .. No. of Blades 15.8 … 3 15.8 … 3 15.8 … 3 18.1 … 3 18.1 … 3
Motor (watts / hp) 23 / 0.102 23 / 0.102 23 / 0.102 53 / 0.224 100 / 0.218
Outdoor Coil
Face Area (sq. ft) 4.05 3.94 3.94 5.51 6.67
No. Rows 2 2 2 4 3
Fins per inch 17 17 17 18 18
Circuits 4 4 4 4 6
Refrigerant Lines
Connection Type Flare
Liquid (Mix Phase) (in) OD 1/4” 1/4” 1/4” 1/4” 3/8”
Vapor Line (in) OD 3/8” 1/2” 1/2” 1/2” 5/8”
Maximum Length* ft (m) 65 (20.0) 65 (20.0) 65 ( 20.0) 100 (30.4) 100 (30.4)
MaxLift(FanCoilAbove)ft(m) 35 (10.7) 35 (10.7) 35 ( 10.7) 50 (12.2) 60 (18.3)
Max Dr op (Fan Coil Below)ft (m) 35 (10.7) 35 (10.7) 35 ( 10.7) 50 (12.2) 60 (18.3)
Controls
Control Voltage 13 VDC 13 VDC 13 V DC Pulse DC Pulse DC
External Finish White White White White White
Outdoor Unit
38MVQ
009 012 012 018 024
System Voltage 115 V 115 V 208/230 208/230 208/230
Nominal Capacity (Btuh) 9000 12000 12000 18000 24000
Operating Weight lb(kg) 72.6 (33) 83.6 (38) 83.6 (38) 117.7 (53.5) 151.0 (68.5)
Refrigerant Type R---410A
Metering Device Capillary Tube at Outdoor
Charge lb (kg) 2.4 (1.1) 3.0 (1.4) 3.0 (1.4) 4.5 (2.0) 5.3 (2.4)
Compressor
Type Rotary
Model EA82X1C---1FZDU1 EA108X1C ---1FZDU1 PA108X1C---3FZDU PA150X2CS---3KUU PA200X2CS --- 3MUU
O i l C h a r g e ( P OE --- o z ) 11.8 11.8 11.8 25.4 25.4
Outdoor Fan
Rpm 900 900 900 840 740
Diameter (in) .. No. of Blades 15.8 … 3 15.8 … 3 15.8 … 3 18.1 … 3 18.1 … 3
Motor (watts / hp) 23 / 0.102 23 / 0.102 23 / 0.102 53 / 0.224 100 / 0.218
Outdoor Coil
Face Area (sq. ft) 4.05 3.94 3.94 5.51 6.67
No. Rows 2 2 2 2 3
Fins per inch 17 18 18 18 18
Circuits 4 4 4 4 6
Refrigerant Lines
Connection Type Flare
Liquid Line (in) OD 1/4” 1/4” 1/4” 1/4” 3/8”
Vapor Line (in) OD 3/8” 1/2” 1/2” 1/2” 5/8”
Maximum Length* ft (m) 65 (20.0) 65 (20.0) 65 (20.0) 100 ( 30.4) 100 (30.4)
MaxLift(FanCoilAbove)ft(m) 35 (10.7) 35 (10.7) 35 (10.7) 50 ( 12.2) 60 (18.3)
Max Dr op (Fan Coil Below)ft (m) 35 (10.7) 35 (10.7) 35 (10.7) 50 (12.2) 60 (18.3)
Controls
Control Voltage 13 VDC 13 VDC 13 VDC Pulse DC Pulse DC
Finish White White White White White
* Refer to Long Line Application section on page 21
